Specification | Description |
---|---|
Work Table Size: | 4-1/8" x 24-7/8" |
Maximum Swing Over Work Table: | 4.92" |
Maximum Distance Between Centers: | 14" |
Traverse of Longitudinal Carriage: | 14.96" |
Traverse of Transversal Carriage: | 7.87" |
Transversal Displacement of Column: | 13" |
Longitudinal Displacement of Column: | 6" |
Verticaal Traverse of Column: | 7.87" |
Vertical Displacement of Motor: | 3.64" |
Column Rotation: | 360 Degrees |
Motor Rotation: | 360 Degrees |
Horizontal Rotation of Workhead: | 360 Degrees |
Vertical Rotation of Workhead: | 360 Degrees |
Indexing Positions: | 16-20-24-36 |
Grinding Wheel Size: | 5.9" x 1/2" |
Overall Machine Dimensions: | 51" x 51" x 64" High |
Machine Weight, Approx.: | 1200 Lbs. |
