| Specification | Description |
|---|---|
| Swing Over Bed Ways: | 21" |
| Swing Over Cross Slide: | 14.5" |
| Maximum Distance Between Centers: | 80" |
| Spindle Speeds (18): | 31 - 1600 RPM |
| Spindle Nose Mount: | D1-8 |
| Tailstock Taper: | #5 MT |
| Threading Range, English: | 2 - 72TPI |
| Threading Range, Metric: | ,2 - 14mm/P |
| Longitudinal Feed Rates: | .0016 - .028"/Rev. |
| Cross Feed Rates: | .0008 - .014"/Rev. |
| Hole Thru Spindle: | 3.125" |
| Overall Dimensions: | 136" x 58" x 58" High |
| Machine Weight, Approx.: | 6000 Lbs. |
