| Specification | Description |
|---|---|
| Table Size: | 11" x 58" |
| X-Axis Travel: | 32" |
| Y-Axis Travel: | 14.5" |
| Z-Axis Travel (Quill): | 4.5" |
| Knee Vertical Travel: | 12" |
| Ram Travel: | 17" |
| Throat Distance Range: | 6" - 22" |
| Table to Spindle Nose Gage Line Range: | 5" - 17" |
| Maximum Uniform Table Load: | 600 Lbs. |
| Spindle Speeds, Variable: | 60 - 4,200 RPM |
| Spindle Nose Taper: | #30 ISO |
| Tool Holder Type: | Erickson QC #30 |
| Axis Feed Rates: | 0.1 - 100 IPM |
| Minimum Increment: | 0.0001" |
| Overall Machine Dimensions: | 82" x 82" x 84" High |
| Machine Weight, Approx.: | 4700 Lbs. |
