| Specification | Description |
|---|---|
| Table Size: | 20" x 94" |
| Longitudinal Table Travel: | 50" |
| Saddle Cross Travel: | 16" |
| Knee Vertical Travel: | 20" |
| Max. Dist. Spdl. Center to Table Top: | 20" |
| Spindle Speeds: | 14 - 1400 RPM |
| Spindle Nose Taper: | No. 50 MT |
| Table Feed Rates: | 3/8 - 90 IPM |
| Max. Cutter Dia. with Overarms: | 15" |
| Overall Machine Dimensions: | 115" x 110" x 84" High |
| Machine Weight, Approx.: | 16,000 Lbs. |
