| Specification | Description |
|---|---|
| Table Size: | 9" x 48" |
| Longitudinal Table Travel: | 33.5" |
| Saddle Cross Travel: | 12" |
| Knee Vertical Travel: | 16" |
| Spindle Quill Travel: | 5" |
| Ram Travel: | 12" |
| Throat Distance Range: | 6.75" - 18.75" |
| Table To Spindle Nose Distance Range: | 2.5" - 18.25 |
| Spindle Speeds, Variable: | 60 - 4,200 RPM |
| Spindle Nose Taper: | R8 |
| Maximum Uniform Table Load: | 300 Lbs. |
| Power Table Feed Rate: | .75" - 35"/Min |
| Overall Machine Dimensions: | 70" x 60" x 86" High |
| Machine Weight, Approx.: | 2,300 Lbs. |
